Specifications
COMBI RX148
| Round Bales (single layer): | 3-6 |
| Medium Squares: | 6-8 |
| Large Squares (8ft long): | 6-8 |
| Loose Silage (load-level): | 14 m³ | 18.3 yd³ |
| Loose Silage (heaped load): | 16.5 m³ | 21.5 yd³ |
| Maximum Load: | 10,000 kg | 22,046 lb |
| Overall Width: | 2950 mm | 116.1 in |
| Overall Length: | 6750 mm | 265.7 in |
| Overall Height/Loading Height: | 2430 mm | 95.6 in |
| Standard Tyres: | 400 / 60 x 15.5 Flotation Grip Tread |
| Axle: | Tandem Walking Beam |
| Brakes | Optional 2 or 4 wheel braking |
| Weigh Scales: | Optional Feedlink weighing and feed management system |
| Floors (Bed Floor / Cross Floor): | 15 mm (0.6 in) HD Puck Board / 12 mm (0.47 in) HD Puck Board |
| Chains (Bed / X floor / Elevator): | Chainless / Twin 12,000 lb Roller Chains / Twin 12,000 lb Roller Chains |
| Feed bars (Bed / X Floor / Elevator): | Twin Hydraulic Rams / 65 x 35 RHS / 40 x 40 RHS |
| Joystick: | In-cab Electric Control w/ Bales and Silage Mode |
| Hydraulics required: | 2 x double-acting |
| Hydraulic Flow: | 50-70 L/min (80 L/min maximum) | 13.2-18.5 gal/min (21.1 gal/min maximum) |
| Hydraulic Pressure: | 2050-2500 psi | 140-170 bar |
| Elevator width: | 1645 mm | 64.7 in wide chain/slat |
| Jack: | 80 mm | 3.1 in 2-speed screw, with quick adjustment. Designed strong enough for use as quick hitch stand |
| Towing Eye | 50 mm | 2 in in swiveling forged eye |
COMBI RX178
| Round Bales: | 3-8 |
| Medium Square Bales: | 8-10 |
| Large Square Bales (8ft long): | 8-10 |
| Loose Silage (Load Level): | 17 m³ | 22.2 yd³ |
| Loose Silage (Heaped Load): | 20.5 m³ | 26.8 yd³ |
| Maximum Load: | 12,000 kg | 26,455 lb |
| Overall Width: | 3000 mm | 118.1 in |
| Overall Length: | 7820 mm | 307.8 in |
| Overall Height/Loading Height: | 2500 mm | 98.4 in |
| Standard Tyres: | 500/45 x 22.5 Flotation Grip Tread |
| Axle: | Tandem Walking Beam |
| Brakes: | Optional 2 or 4 Wheel Braking |
| Weigh Scales: | Optional Feedlink weighing and feed management system |
| Floors (Bed Floor / Cross Floor): | 15 mm (0.6 in) HD Puck Board / 12 mm (0.47 in) HD Puck Board |
| Chains (Bed / X floor / Elevator): | Chainless / Twin 12,000 lb Roller Chains / Twin 12,000 lb Roller Chains |
| Feed bars (Bed / X Floor / Elevator): | Twin Hydraulic Rams / 65 x 35 RHS / 40 x 40 RHS |
| Joystick: | In-cab Electric Control w/ Bales and Silage Mode |
| Hydraulics Required: | 2 x double-acting |
| Hydraulic Flow: | 50-70 L/min (80 L/min maximum) | 13.2-18.5 gal/min (21.1 gal/min maximum) |
| Hydraulic Pressure: | 2050-2500 psi | 140-170 bar |
| Elevator: | 1645 mm | 64.7 in wide chain/slat |
| Jack: | 80 mm | 3.1 in 2-speed screw, with quick adjustment. Designed strong enough for use as quick hitch stand |
| Towing Eye | 50 mm | 2 in in swiveling forged eye |
COMBI RX218
| Round Bales: | 4-10 |
| Medium Square Bales: | 10-14 |
| Large Square Bales (8ft long): | 10-14 |
| Loose Silage (Load Level): | 21.4 m³ | 27.9 yd³ |
| Loose Silage (Heaped Load): | 26 m³ | 34 yd³ |
| Maximum Load: | 17,000 kg | 37,478 lb |
| Overall Width: | 3035 mm | 119.4 in |
| Overall Length: | 9180 mm | 361.4 in |
| Overall Height | 2650 mm | 104.3 in |
| Standard Tyres: | 500/45 x 22.5 Flotation Grip Tread |
| Axle: | Tridem Steering Suspension Axle |
| Brakes: | Optional 4 or 6 Wheel Braking |
| Weigh Scales: | Optional Feedlink weighing and feed management system |
| Floors (Bed Floor / Cross Floor): | 15 mm (0.6 in) HD Puck Board / 12 mm (0.47 in) HD Puck Board |
| Chains (Bed / X floor / Elevator): | Chainless / Twin 12,000 lb Roller Chains / Twin 12,000 lb Roller Chains |
| Feed bars (Bed / X Floor / Elevator): | Twin Hydraulic Rams / 65 x 35 RHS / 40 x 40 RHS |
| Joystick: | In-cab Electric Control w/ Bales and Silage Mode |
| Hydraulics Required: | 2 x double-acting |
| Hydraulic Flow: | 50-70 L/min (80 L/min maximum) | 13.2-18.5 gal/min (21.1 gal/min maximum) |
| Hydraulic Pressure: | 2050-2500 psi | 140-170 bar |
| Elevator: | 1645 mm | 64.7 in wide chain/slat |
| Jack: | 80 mm | 3.1 in 2-speed screw, with quick adjustment. Designed strong enough for use as quick hitch stand |
| Towing Eye | 50 mm | 2 in in swiveling forged eye |
