GrabMax Silage Grabs
GrabMax Silage Grabs
Specifications
LM160
| This model is available in | Australia, United Kingdom & Ireland |
| Unit Weight | 300 kg | 661.3 lbs |
| Dimensions (L x W x H) | 1600 mm x 1000 mm x 880 mm | 62.9 in x 39.3 in x 34.6 in |
| Capacity | 0.88 m³ | 10.3 yd |
| Tines (top) | 8/7 forged tines |
| Clamp | Twin ram clamp |
LM200
| This model is available in | Australia, United Kingdom & Ireland |
| Unit Weight | 320 kg | 705.4 lbs |
| Dimensions (L x W x H) | 1800 mm x 1000 mm x 880 mm | 70.8 in x 39.3 in x 34.6 in |
| Capacity | 0.99 m³ | 34.9³ |
| Tines (bottom/top) | 9/8 forged tines |
| Clamp | Twin ram clamp |
LM240
| This model is available in | Australia, United Kingdom & Ireland |
| Unit Weight | 410 kg | 903 lbs |
| Dimensions (L x W x H) | 2400 mm x 1000 mm x 880 mm | 94.4 in x 39.3 in x 34.6 in |
| Capacity | 1.32 m³ | 11.7yd |
| Tines (bottom/top) | 12/11 forged tines |
| Clamp | Twin ram, split clamp |
LX200
| This model (heavy duty) is exclusive to | the United States and Canada |
| Unit Weight | 530 kg | 1102.3 lbs |
| Dimensions (L x W x H) | 2000 mm x 1210 mm x 1020 mm | 773/4 in wide x 472/3 in deep x 40.15 in – 58.18” high |
| Capacity | 1.80 m³ | 21.2 yd |
| Tines (bottom/top) | 10/9 forged tines |
| Clamp | Twin ram, split clamp |
LX250
| This model (heavy duty) is exclusive to | the United States and Canada |
| Unit Weight | 580 kg | 1278.7 lbs |
| Dimensions (L x W x H) | 2500 mm x 1210 mm x 1020 mm | 98.4 in x 47.6 in x 40.1 in |
| Capacity | 2.25 m³ | 26.5yd |
| Tines (bottom/top) | 13/12 forged tines |
| Clamp | Twin ram, split clamp |
